- Specifications
- Application
- Product Detail
| Motor Body | : | SS304 |
| Stator Stamping | : | Electrical Grade Silicon Steel |
| Thrust Bearing | : | SS420 Segment With Carbon Plate |
| Rotor Shaft | : | SS420 / SS431 |
| Bush | : | GM LTB4 |
| Seal | : | Nitrile Rubber |
| Winding Wire | : | Polywrap Doublecoated Copper Wire |
| Upper & Lower Bearing Housing | : | CI FG 200 WITH CED COATING COVERD WITH SS 304 JACKET |
| Rewindable | ||
| Degree Of Protection | : | IP 68 |
| Max Water Temperature | : | 35° C |
| Nos. Of Start Per Hour | : | Max 20 At Regular Intervals |
| Voltage Variation | : | +6% / -10% At Rated Voltage. |
| Motor Cable Length | : | 3.0 meters (3 core) |
| Mounting | : | NEMA Standards Vertical |
| Power Range | : | Single Phase : 0.37 kW-2.2 kW AC Single Phase Operating Voltage Band : 180-240 V , 50HZ Three Phase : 0.75 kW-7.5 kW AC Three Phase Operating Voltage Band : 1: 300-415 V , 50HZ |
| Speed | : | 2800 RPM |
- Residential Purpose
- Irrigation
- Fountains
- Industrial water supply
- Pressure Boosting Units
- Gardens & Horticulture
- Drip & Sprinkler Systems
- Mining Industries
- Oil & Gas Industries
| Model | KW | HP | MOTOR LENGTH (MM) |
|---|---|---|---|
| W4SP0005H5SSCL | 0.37 | 0.5 | 441.5 |
| W4SP0007H5SSCL | 0.55 | 0.75 | 481.5 |
| W4SP0010H5SSCL | 0.75 | 1 | 481.5 |
| W4TP0010H5SSCL | |||
| W4SP0015H5SSCL | 1.1 | 1.5 | 511.5 |
| W4TP0015H5SSCL | |||
| W4SP0020H5SSCL | 1.5 | 2 | 571.5 |
| W4TP0020H5SSCL | |||
| W4SP0030H5SSCL | 2.2 | 3 | 646.5 |
| W4TP0030H5SSCL | |||
| W4TP0040H5SSCL | 3 | 4 | 716.5 |
| W4TP0050H5SSCL | 3.7 | 5 | 716.5 |
| W4TP0075H5SSCL | 5.5 | 7.5 | 846.5 |
| W4TP0100H5SSCL | 7.5 | 10 | 971.5 |
NOTE : W4 – 4” MOTOR, SP – SINGLE PHASE , TP- THREE PHASE , SSCL – STAINLESS STEEL CLADDING
